Model | T85i | T100i | T120i | T90i | T105i |
Basic parameters | |||||
Type | Counterattack crusher | Jaw crusher | |||
Max. feed size（mm） | 500 | 600 | 800 | 500 | 630 |
Product size range（mm） | 0-40 | 0-40 | 0-40 | 0-50 | 0-60 |
0-100 | 0-150 | 0-150 | 0-150 | 0-200 | |
Adjustment range（mm） | 40-100 | 40-150 | 40-150 | 50-150 | 60-200 |
production capacity（t/h） | 50-150 | 100-200 | 150-250 | 80-200 | 140-400 |
Installed power（KVA） | 210 | 250 | 275 | 210 | 250 |
Power | Diesel generator / motor / hydraulic | ||||
Discharge parameters | |||||
Discharge height of main conveyor（mm） | 3100 | 3100 | 3100 | 3100 | 3100 |
Discharge height of side conveyor（mm） | 2500 | 2650 | 2850 | 2500 | 2850 |
Working state dimensions | |||||
length（mm） | 12500 | 13500 | 14000 | 13500 | 14000 |
width（mm） | 2500 | 2600 | 2650 | 2600 | 2650 |
height（mm） | 3200 | 3500 | 3700 | 3650 | 3800 |
Driving parameters | |||||
Moving speed（km/h） | 2 | ||||
Gradient（%） | 35 | ||||
Total weight | |||||
Transport weight（t） | 28 | 35 | 42 | 36 | 42 |
